Narrow shear-lock magnetic lock with monitoring - 600kg
Shear-Lock locks are flat magnets that hold against shear forces (forces acting parallel to the surface). With their help, significant holding force can be achieved, even with a small lock.
The YM-2300SL is an electromagnetic Shear-lock with a holding force of 600kgf (parallel to the surface), designed for surface mount and operates with 12/24 V DC. Provided lock and door status (NO-NC-COM) indication. It is iIdeal for ensuring the secure closure of precisely fitting solid doors.
After the closed position is detected, the re-locking delay can be adjusted using a DIP switch between 0 and 15 seconds.
Description
|
Electromagnetic locks (flat magnets) provide an ideal solution for all types of doors. These locks are vandal-proof, do not contain moving mechanical parts, thus can be operated safely in the long term. Installation is simple and can be securely mounted in various ways using mounting brackets. WARNING! Electromagnetic locks must be installed in an internal, so called protected environment, so that unauthorized individuals cannot access either the attachment points or the wires. |
Downloads
Specifications
| Voltage (V) | 12 / 24 V |
|---|---|
| Voltage type | DC |
| Stand-by current consumption (A) | 300 mA (12 V) |
| Holding force (N) | 5884 N |
| Holding force (kgf) | 1200 kgf |
| Operating modes | needs power to close |
| Build-in release button | none |
| Opening possibilities | controlled electrical signal |
| Type of control | power cut |
| Behaviour (in case of power off) | Fail-safe |
| Product family | YLI Shear Lock |
| Monitoring | lock sensor , door sensor, LED |
| Type of monitoring | Reed relay, HALL sensor |
| Lock monitoring signal type | NO/NC |
| Door monitoring signal type | NO/NC |
| Field of use | outward opening, inward opening, entrance doors, wooden doors |
| Installation area | indoor, outdoor |
|---|---|
| Mounting | flush mounted |
| Package contents | Electromagnet with factory mounting possibilities, armature plate, screw set, hex key |
| Related brackets | MBK-2300I |
| Preloaded door opening | no |
| Dimensions | 214 x 18 x 22 mm |
| Dimension of armature plate | 214 x 18 x 22 mm |
| Mortise dimension | 144 x 30 x 18 mm (electromagnet) 136 x 30 x 19,5 mm (counter part) |
| IP rating | unclassified |
| Environmental temperature | -30 °C ~ +50 °C |
| Gross weight | 0,7 kg |
| Warranty | 36 months |
| Certificates | CE |
| Manufacturer | YLI |
| Product category | A |
